| NOV P/N | DESCRIPTION |
| 109505-3 | BAIL, 500 TON-120.0'' LONG |
| 109505-3LT | BAIL, 500 TON-120" LONG, LOW TEMP |
| 109505-4 | BAIL, 500 TON-88.0'' LONG |
| 30178669 | BAIL, MODIFIED, 500 TON, 120" LONG |
| 110077 | LUG, COUNTERBALANCE |
| M614003027 | LUG, COUNTERBALANCE |
| 110070 | BUTTON, COUNTERBALANCE |
| 50012-20-C5D | SCREW, HEX HEAD CAP |
| 50912-C | WASHER, LOCK - REGULAR 3/4" |
| 109506 | PIN, BAIL, (CARRIAGE) |
| 110123 | RETAINER, PIN, BAIL (CARRIAGE) |
| 109507 | BUSHING, BAIL PIN |
| 53201 | FITTING, GREASE, STRAIGHT |
| 50008-9-C5D | SCREW, HEX HEAD CAP |
| 50908-C | WASHER, LOCK, REGULAR, 1/2 |
| Z6001 | SAFETY LOCKWIRE OD 0.051'' |
| Z6000.9 | SAFETY LOCKWIRE OD 0.047'' |
| 3012453-BSC | CARRIAGE ASSY, RIGHT, 30.00'' SETBACK |
| 3012453-502 | CARRIAGE ASSY, RIGHT, 39.50'' SETBACK |
| 3012453-501 | CARRIAGE ASSY, RIGHT, 33.75'' SETBACK |
| 3012453-503 | CARRIAGE ASSY, RIGHT, 41.00'' SETBACK |
| 124538-BSC | CARRIAGE ASSY, LEFT, 30.00'' SETBACK |
| 124538-502 | CARRIAGE ASSY, LEFT, 39.50'' SETBACK |
| 124538-501 | CARRIAGE ASSY, LEFT, 33.75'' SETBACK |
| 124538-503 | CARRIAGE ASSY, LEFT, 41.00'' SETBACK |
| 51222-12-16 | DOWEL PIN, HARDENED |
| 939390-10 | WASHER, FLAT, HARDENED |
| 50016-20-C | CAPSCREW, HEX HEAD |
| 141510 | CARRIAGE SPACER, 39.50” SETBACK |
| 124535 | CARRIAGE, LEFT, 30'' SETBACK, DS |
| 124535-502 | CARRIAGE, LEFT, 39.50'' SETBACK, DS |
| 124535-500 | CARRIAGE, LEFT, 33.75'' SETBACK, DS |
| 124535-503 | CARRIAGE, LEFT, 41.00'' SETBACK, DS |
| 30155438 | CAM FOLLOWER 6'' |
| 51132-C | WASHER, LOCK, HI-COLLAR, D 2" |
| 80569 | JAM NUT 2 – 12UN-2B |
| 109944 | FLANGED BUSHING 2.75ID |
| 124537 | BOGEY |
| 112875 | PIN, BOGEY, TDS 11 CARRIAGE |
| 51024-C | WASHER, FLAT |
| 55324-C | NUT, HEX, STOVER C 1 1/2-12 |
| 30158767-04 | BEARING, CAM FOLLOWER |
| 30179918 | BOLT, SHOULDER |
| 125727-3 | FERRULE BAR |
| 30157306 | PIN, LYNCH, STANDARD |
| 125727-1 | PLATE, CARRIAGE |
| 125727-2 | PLATE, CARRIAGE |
| 51220-2 | CABLE, STAINLESS, D 0.063 X 24'' / 48'' / 72'' LONG, NYLON COATED |
| 51219-2 | FERRULE, CABLE |
| 50812-N-C | WASHER, FLAT |
| 50512-C | NUT, HEX, SLOTTED |
| 30152845 | Pin |
| 51402-12-S | PIN, COTTER |
| 50008-10-C5D | CAPSCREW, HEX HEAD |
| 50108-10-CD | 25 50108-10-CD 026211.0820DH2 CAPSCREW, SOCKET HEAD 2 (ALL) |
| 113370 | 26 113370 M102403 STRAP, ACCUMULATOR, 6” 1 (ALL) |
| 50006-5-C5D | 27 50006-5-C5D 008121.0610DH2 CAPSCREW, HEX HEAD 2 (ALL) |
| 50906-C | WASHER, LOCK, SPLIT, GR8, 3/8 |
| 88710 | 29 88710 M105798 STRAP, CARRIAGE 2 (ALL) |
| 129375 | 30 129375 M105799 BRACKET, ANGLE 1 (ALL) |
| GREASE CAP | GREASE CAP |
| 124536 | CARRIAGE, RIGHT, 30'' SETBACK, ODS |
| 124536-502 | CARRIAGE, RIGHT, 39.50'' SETBACK, ODS |
| 124536-500 | CARRIAGE, RIGHT, 33.75'' SETBACK, ODS |
| 124536-503 | CARRIAGE, RIGHT, 41.00'' SETBACK, ODS |
| 301555438 | CAM FOLLOWER 6'' |
| 53000-2-C | PLUG, EXT PIPE, CTSK / HEX |
| 110704 | CYLINDER ASSEMBLY, COUNTERBALANCE |
| 110703 | CYLINDER ASSEMBLY, COUNTERBALANCE |
| 59144P290099 | HOSE ASSY |
| 59124P290093 | HOSE ASSY |
| 59143P290086 | HOSE ASSY |
| 81560 | LABEL |
| 76717 | LINK, PEAR |
| 110687 | CYLINDER, 4'' COUNTERBALANCE |
| 111935 | CLEVIS, ROD END, CYLINDER, COUNTERBALANCE |
| 110716-2 | MANIFOLD, RELIEF, COUNTERBALANCE |
| 51300-214B | O RING |
| 94522-21N | CARTRIDGE, VALVE, PHM31 |
| 111936 | TUBE, CYLINDER, COUNTERBALANCE |
| 56519-12-12S | ELBOW, O-RING BOSS, 37DEG |
| 30172176-BSC | PIN, CLEVIS, CYLINDER, COUNTERBALANCE |
| 50516-C | NUT, HEX, SLOTTED |
| 51437-16-S | PIN, COTTER |
| 94681-12 | BLIND FLANGE KIT |
| 30172176-502 | PIN, CLEVIS, CYLINDER, COUNTERBALANCE |
| 87196-12-S | PLUG, SAE-12 HEX SOCKET |
| 88484 | SHACKLE (13.5 TON) |
| 80392 | LINK, CONNECTING |
| 80390-2 | HAIN, 4 LINK |
| 96575 | SHACKLE |
| 117076 | COUNTER BALANCE BEAM |
| 51405-18-S | PIN, COTTER (NOT SHOWN |
| 121227 | BODY, MAIN – 500 TON |
| 109518 | COVER, MAIN BODY |
| 121131 | MAIN SHAFT W/LANDING COLLAR |
| 30120556 | BEARING, THRUST – TAPER ROLLER |
| 109521 | (MT) BEARING, ROLLER, CYLINDRICAL, 200 X 360 MM, ROLLER, MAIN LOWER |
| 109591 | SLEEVE, WEAR |
| 117987 | BEARING, ROLLER, SPHERICAL, 80 X 170 |
| 109539 | RING, SPACER |
| 88990-10 | NOZZLE, SPRAY-FLAT PATTERN |
| 94821 | PLUG, MODIFIED |
| 53200-242 | COMPOUND, LOCKING (BLUE) |
| 51216-24 | PIN, DOWEL |
| 88990-9 | NOZZLE, SPRAY-FLAT PATTERN |
| 96648-1 | RING, RETAIN, INT, PHM3I, (TDS9S) |
| 51300-016-B | O RING |
| 51300-223-F | O-RING |
| 30158573 | GEAR, COMPOUND, HELICAL |
| 109522 | BEARING, CYLINDRICAL, ROLLER, COMPOUND UPPER |
| 91829-1 | STEM SLEEVE |
| 109519 | BEARING, TAPER ROLLER |
| 91250-1 | (MT) OIL SEAL (VITON), STD. BORE, TDS |
| 98291 | SEAL, POLYPAK, 3.875, STD. BORE, TDS |
| 98290 | LINER, UPPER STEM |
| 30158574 | GEAR, BULL, HELICAL |
| 50016-28-C5D | SCREW, HEX HEAD CAP |
| 50916-C | WASHER, LOCK – REGULAR |
| 53000-8-C | PLUG, EXT PIPE |
| 53000-48-C | PLUG, EXT PIPE- COUNTERSUNK HEX |
| 53000-4-C | PLUG, EXT PIPE – COUNTERSUNK HEX |
| 30173521 | BEARING ISOLATOR |
| 30176112 | RETAINER, BEARING, - UPPER STEM |
| 51218-18 | LOCKNUT, LOW CARBON STEEL |
| 51217-18 | WASHER, BEARING LOCK, LOW CARBON STEEL |
| 53000-1-S | PLUG, EXT PIPE – COUNTERSUNK HEX |
| 51300-387-F | O-RING, VITON |
| 109586-1 | SHIM, 0.002, UPPER BEARING |
| 109586-2 | SHIM, 0.005, UPPER BEARING |
| 109586-3 | SHIM, 0.010, UPPER BEARING |
| 109586-4 | SHIM, 0.015, UPPER BEARING |
| 109586-5 | SHIM, 0.020, UPPER BEARING |
| 109566-2 | TUBE, UPPER BEARING LUBE |
| 109594 | COVER, BEARING |
| 109594-1 | COVER, BEARING |
| 51300-258-B | O RING |
| 53003-16 | PLUG, MAGNETIC |
| 109593 | RETAINER, BEARING |
| Z6001.9 | LOCK WIRE,.047 |
| 50012-24-C5D | SCREW, HEX HEAD CAP |
| 50012-26-C5D | SCREW, HEX HEAD CAP |
| 50012-16-C5D | SCREW, HEX HEAD CAP |
| 53000-12-S | PLUG, EXT PIPE – COUNTERSUNK HEX |
| 53000-6-C | PLUG, EXT PIPE – COUNTERSUNK HEX 3/8 |
| 94041-18 | PLUG ORIFICE.071 PHM3I |
| 94042-12 | PLUG ORIFICE .047 PHM |
| 53002-32-C | PLUG, PIPE – SQUARE HEAD |
| 53000-2-S | PLUG, EXT PIPE – COUNTERSUNK HEX |
| 30154362 | SHIELD, BEARING |
| 30123920 | ASSY, WASHPIPE, 7500 PSI |
| 117603-1 | PUMP ASSEMBLY, LUBE |
| 51300-279-B | O-RING |
| 50008-12-C5D | SCREW, HEX HEAD CAP |
| 50004-6-C5D | SCREW, HEX HEAD CAP |
| 94269-2 | CLAMP, SINGLE – 1/4" TUBE PHM- 3i |
| 50904-C | WASHER, LOCK – REGULAR |
| 121272-2 | TUBE ASSEMBLY, BREATHER |
| 56506-6-4-S | ELBOW, 90 EXT/37 |
| 30171072 | BRACKET, LUBE SWITCH |
| 121272-1 | TUBE ASSEMBLY, BREATHER |
| 110010 | COVER, ACCESS |
| 110011 | MT GASKET COVER ACCESS |
| 53912-B | NIPPLE, CLOSE |
| 52212-B | ELBOW, 90 – COMMON, (150LB) |
| 52824-12-B | BUSHING, PIPE REDUCING- COMMON |
| 108216-12 | PDM4 BALL VALVE 3/4-14 BRASS |
| 110844-52 | PLUG ORIFICE.250NPT.205 |
| 118217-40R60 | MOTOR ASSY, DRILL AC-575, VAC (RH) (400 HP) |
| 118217-40L60 | MOTOR ASSY, DRILL, AC-575, BAC (LH) (400HP) |
| 30173277 | ROTATING LINK ADAPTER ASSY – 500 TON |
| 110068-2 | ASSEMBLY, RESERVOIR, HYDRAULIC OIL |
| 30151875-504 | HYD DRIVE/ SHOTPIN ASSY ROT LINK ADAPT |
| 30122104 | HEAT EXCHANGER, OIL |
| 122249 | BRACKET, HEAT EXCHANGE |
| 51300-277-B | O RING |
| 109523 | ADAPTER, S-PIPE |
| 50010-18-C5D | CAPSCREW, HEX HEAD, 5/8-11UNC X 2.25,DH2, GR5 |
| 50910-C | WASHER, LOCK – REGULAR |
| 110147-1 | SHIM, RESERVOIR MOUNTING,.002 |
| 110147-2 | SHIM, RESERVOIR MOUNTING,.005 |
| 110147-3 | SHIM RESERVOIR MOUNTING,.010 |
| 110147-4 | SHIM, RESERVOIR MOUNTING,.031 |
| 51300-425-B | O-RING |
| 105520 | PLAQUE, I.D., TDS-11SA |
| 110008 | O-RING,.275X50.5 |
| 50012-18-C5D | SCREW, HEX HEAD CAP |
| 119977 | LABEL, WARNING, NOV TDS-11S |
| 116661-1 | MOUNTING PLATE, MOTOR |
| 51300-385-F | O RING |
| 118378 | RETAINER, LANDING COLLAR |
| 118377 | COLLAR, LANDING (SET) |
| 50008-11-C5D | SCREW, HEX HEAD, 1/2-13 X 1-3/8, GR5 |
| 30184361-520 | GREASE, EXTREME SERVICE, JET-LUBE |
| 30172028-1 | BLOWER MOTOR, U.L., 575 VAC /60 HZ |
| 109592-3 | COVER, BLOWER SCROLL BRAKE (LEFT) |
| 30126111-1 | MOUNTING PLATE, BLOWER MOTOR |
| 109563-1 | DUCT |
| 110110-1 | GASKET DUCT BLOWER |
| 110116 | MT GASKET MOTOR PLATE |
| 110112-1 | GASKET, BLOWER SCROLL |
| 30172172 | CAPSCREW, HEX HEAD |
| 50506-C | NUT, HEX, SLOTTED |
| 51401-8-S | PIN, COTTER |
| 50905-C | WASHER, LOCK – REGULAR |
| 50006-10-C5D | CAPSCREW, HEX HEAD, 3/8-16UNC X 1.25, DH |
| 50008-7-C5D | SCREW, HEX HEAD CAP |
| 50005-10-C5D | SCREW, HEX HEAD CAP |
| 109592-4 | COVER, BLOWER SCROLL BRAKE (RIGHT) |
| 110001 | COVER, BLOWER |
| 110014 | GASKET BLOWER 7.6X12.5 |
| 115879 | MOUNT CABLE |
| 109561-1 | IMPELLER, BLOWER |
| 109563-2 | DUCT |
| 109561-4 | BUSHING, SPLIT TAPER, 28MM |
| 120462 | LABEL, INSTRUCTIONS |
| 122248 | FASTENING BLOCK |
| 50006-18-C5D | SCREW, HEX HEAD CAP |
| 109528 | BRAKE, CALIPER DISC |
| 109555 | ROTOR, BRAKE |
| 109553 | ADAPTER PLATE, BRAKE |
| 109557 | WASHER, 300SS |
| 56529-10-8-S | CONNECTOR, EXT PIPE/37 |
| 122247-1 | TUBE, HEAT EXCHANGER – 1/2" |
| 122247-2 | TUBE, HEAT EXCHANGER – 1/2" |
| 110173 | TUBE ASSEMBLY, BRAKE |
| 110172 | TUBE ASSEMBLY, BRAKE |
| 117116 | TUBE ASSEMBLY, BRAKE, RIGHT |
| 50112-20-BD | SCREW, CAP-HEX HEAD (UNC-2A) |
| 30171956 | TUBE ASSEMBLY, BRAKE, BOTTOM |
| 30179069 | BLOWER MOTOR, U.L., 575 VAC /60 HZ |
| M614003119-BSC | ASSY, ENCODER, DIGITAL |
| 120114 | MOUNTING BRACKET, ENCODER |
| 120116 | SHAFT ADAPTER |
| 120113 | MOUNT ENCODER |
| 120112 | MOUNT, SLED |
| 120119-1 | PULLEY, TIMING |
| 120119-2 | PULLEY, TIMING |
| 120115 | SPRING |
| 120117 | BELT, TIMING |
| 113246 | BRACKET, PRE- FILL VALVE |
| 122943-501 | MOUNT, PLATE, ENCODER |
| 122956 | SPACER |
| 122953-500 | ARM, TENSIONER, SUPPORT |
| 122955 | SPRING, TORSION |
| 122944 | ADAPTER, SHAFT |
| 120117-3 | BELT, TIMING, ENCODER |
| 122946 | PULLEY, TIMING |
| 120118 | PULLEY, TIMING |
| 122725 | ENCODER, DIGITAL |
| 122948 | BEARING, BALL, DEEP-GROOVE |
| 122949 | LABEL, INSTRUCTIONS |
| 122952 | RING, RETAINING |
| 122947 | PULLEY, TENSIONER |
| 30177460 | COVER, BLOWER |
| M614000689 | PIN, EEx ENCODER TENSIONER SUPPORT ARM |
| 56003 | GREASE, SEVERE SERVICE |
| M614002976-500 | ASSY, PLATE, MOTOR DUCT /POWER (RIGHT) |
| M614002976-501 | ASSY, PLATE, MOTOR DUCT /POWER (LEFT) |
| 118868-8 | SHACKLE, ANCHOR, 8.5 TON |
| 110078-FL2 | FERRULE, SAFETY CABLE,.032 |
| 110078-FL18 | FERRULE, SAFETY CABLE,.032 |
| 110078-L36 | CABLE, SAFETY.032 X 36" |
| 110039 | PIN, DOWEL |
| 122954-2 | SPACER |
| 56506-16-16-S | ELBOW, 90 EXT/37 |
| M614000690 | BUSHING, SUPPORT ARM |
| 53300-526 | TIE, CABLE (TY -RAP) |
| 56502-2-4-S | ELBOW, 45, O-RING BOX /37 |
| 56519-12-8-S | ELBOW, O-RING BOSS/37 |
| 56525-4-4-S | TEE, SWIVEL INT, 37/37/37 |
| 56526-4-4-S | ELBOW, 90 EXT/37 |
| 56529-4-4-S | CONNECTOR, O-RING BOSS/37' 7/16''-20 X 1/4'' |
| 56531-4-S | PLUG, O-RING BOSS (WITH O-RING) |
| 56531-8-S | PLUG, O-RING BOSS (WITH O-RING) |
| 110078-L12 | CABLE, SAFETY,.031 |
| 50004-12-C5D | SCREW, HEX HEAD CAP |
| 50004-4-C5D | SCREW, HEX HEAD CAP |
| 50004-5-C5D | SCREW, HEX HEAD CAP (also 240) |
| 50005-12-C5 | CAPSCREW, HEX HEAD, 5/16-18UNC X 1.50,DH, GR5 |
| 50005-8-CD | CAPSCREW, HEX HEAD, 5/16-18UNC X 1.00,DH, |
| 50006-12-C5D | CAPSCREW, HEX HEAD, 3/8-16UNC X 1.50, DH |
| 50006-20-C5D | SCREW, HEX HEAD CAP |
| 50006-6-C5D | SCREW, HEX HEAD CAP |
| 50008-8-C5D | CAPSCREW, HEX HEAD,1/2-13UNC X 1.00,DH2 |
| 50010-10-C5D | CAPSCREW, HEX HEAD,5/8-11UNC X 1.25,DH2 |
| 50012-12-C5D | SCREW, HEX HEAD CAP |
| 50016-12-C5D | SCREW, HEX HEAD CAP |
| 50016-18-C5D | SCREW, HEX HEAD CAP |
| 50069-22-F08 | SCREW, CAP-HEX HEAD (METRIC) |
| 50103-5-C5D | SCREW, SOCKET HEAD CAP |
| 50104-8-C | SCREW, SOCKET HEAD CAP |
| 50168-12-F06 | SCREW, SOCKET HEAD CAP |
| 50804-N-S | WASHER, FLAT NARROW |
| 50804-R-S | WASHER, FLAT |
| 50806-R-C | WASHER, FLAT, 3/8" |
| 50903-C | WASHER, REGULAR-LOCK |
| 51401-6-S | PIN, COTTER |
| 51433-6-S | PIN, COTTER |
| 51604-8-S | PIN, ROLL |
| 53301-4-4-SS | SCREW, DRIVE, TYPE U |
| 55504-C | NUT, HEX SLOTTED |
| 110078-L18 | CABLE, SAFETY.032 X 18'' |
| 109538 | RING, RETAINING, INTERNAL |
| 110040-1 | SLEEVE, MAINSHAFT |
| 30155874 | GEAR, BULL, HELICAL |
| 109531 | BONNET |
| 50112-20-C5D | SCREW, CAP-HEX HEAD (UNC-2A) |
| 30171957 | TUBE ASSEMBLY, BRAKE, UPPER |
| M614003119- BSC | ASSY, ENCODER, DIGITAL |
| M614000690 | BUSHING, SUPPORT ARM |
| 118217- | AC MOTOR |
| 117939 | PINION GEAR, HELICAL (MACHINING) |
| 109554 | HUB, BRAKE |
| 115040 | PINION INSTALLATION SUPPLIES |
| 120994 | LOUVER, DRILL MOTOR |
| 30113619 | SCREEN, LOUVER |
| 120995 | COVER, LOUVER, DRILL MOTOR |
| 30173795-1 | INSTRUCTIONS, HAZARDOUS AREA SAFETY |
| 30173795-2 | NAMEPLATE, CERTIFICATION |
| 30173795-3 | INSTRUCTIONS, HAZARDOUS AREA SAFETY |
| 30173795-BSC | NAMEPLATE, CERTIFICATION |
| 78736-14 | CLAMP, SUPPORT, 2.25 ID |
| 53002-02-C | PLUG, PIPE-SQ HD |
| 51208-14 | PIN, DOWEL |
| 53301-04-03-C | SCREW, DRIVE |
| 50005-6-C5D | SCREW, CAP-HEX HEAD DRILLED |
| 50006-8-C5D | SCREW, CAP-HEX HEAD DRILLED |
| 117575-1 | ADAPTER PLATE, LUBE PUMP (ALUM ALLOY) |
| 117575 | ADAPTER PLATE, LUBE PUMP (STEEL) |
| 109579 | ADAPTER, MOTOR/PUMP |
| 30156326-36S | HYDRAULIC MOTOR LOW-SPEED/ HIGH TORQUE |
| 109567-H203 | P50 PUMP (GEAR HOUSING) |
| 109567-G20 | P50 PUMP (GEAR SET) |
| 109567-B | P50 PUMP (ROLLER BEARING) |
| 109567-E | P50 PUMP (END COVER) |
| 109567-1 | P50 PUMP (THRUST PLATE) |
| 109567-S | P50 PUMP (BODY SEAL) |
| 108119-16B | PDM HPU SIGHT GAUGE |
| 71033 | GASKET, MOTOR |
| 53000-16-C | PLUG, SOC HEX, 1 NPT |
| 56519-16-16-S | ELBOW, O-RING BOSS /37 |
| 50010-40-C5D | SCREW, CAP-HEX HEAD |
| 53418 | PLUG, PLASTIC, PIPE CLOSURE 1-5/16 SAE |
| 53408 | PLUG, PLASTIC, PIPE CLOSURE |
| 108465-24 | PLUG, SHIPPING, SAE O-RING PORT |
| 110067 | RESERVOIR, HYDRAULIC OIL |
| 111915 | COVER TOP, RESERVOIR |
| 110191-500 | BLADDER, RESERVOIR (4 GALLONS) |
| 110191-501 | BLADDER, RESERVOIR (5 GALLONS) |
| 110132 | GASKET |
| 51300-038-B | O-RING |
| 107865-16 | STRAINER, SUMP |
| 71613 | RESERVOIR BREATHER |
| 82570 | ADHESIVE, RUBBER |
| 30113165 | VALVE, RELIEF-POPPET |
| 110013 | BRACKET |
| 56506-8-6-S | ELBOW, 90 EXT/37 |
| 56506-12-12-S | ELBOW, 90 EXT/37 |
| 56506-16-16-S | ELBOW, 90 EXT/37 |
| 53406 | CAP, PLASTIC PIPE CLOSURE 9/16 SAE |
| 53415 | CAP, PLASTIC PIPE 1-1/16 SAE |
| 50908-S | WASHER, LOCK-REGULAR, SS |
| 50008-12-SD | SCREW, CAP-HEX HEAD |
| 50904-S | WASHER, LOCK-REGULAR |
| 50004-5-SD | SCREW, CAP-HEX HEAD (UNC-2A) |
| 50004-10-SD | SCREW, CAP-HEX HEAD (UNC-2A) |
| 30177314-500 | STEM |
| 30177594-500 | STEM |
| 30173159 | ROTATING LINK ADAPTER |
| 30173157 | GEAR, ROTATING LINK ADAPTER (500 TON) |
| 30119143 | RING, GLYD, 11.50 ROTARY |
| 30119319 | RING GLYD 11.00 ROTARY |
| 30119357 | RING THRUST |
| 30173156 | PISTON RING |
| 30177233 | PISTON RING |
| 30114594 | BOLTS, CATCH LINK |
| 124029 | SHAFT, PIVOT-LOCKING PIN (RLA 500 TON) |
| 119547 | SEAL WIPER |
| 119359 | RETAINER OIL SEAL |
| 119358 | BUSHING, TURCITE |
| 119124 | STOP (RLA 500 TON) |
| 118375 | GLYD RING ROTARY 10.000 |
| 115176 | BUSHING SLEEVE 1.0X1.25 |
| 77039 | SEAL |
| 112754-116 | BEARING SINTERED BRONZE FLANGED |
| 112754-130 | BEARING SINTERED BRONZE FLANGED |
| 30117775-2 | RING RETAINER EXTERNAL |
| 112809 | CAP |
| 51300-273-B | O-RING |
| 51300-381-B | O RING |
| 53002-12-S | CONNECTOR, O-RING BOSS/ 37 |
| 53200-271 | COMPOUND, LOCKING (RED) |
| 53250-5 | RELIEF VALVE |
| 56529-8-4-S | CONNECTOR, O-RING BOSS/ 37 |
| 56529-8-6-S | CONNECTOR, O-RING BOSS/ 37 |
| 51405-24 | PIN, COTTER |
| 51437-20-S | PIN, COTTER |
| 50020-24-C5D | SCREW, CAP-HEX HD |
| 50320-C | NUT, HEX-JAM |
| 50520-C | NUT, HEX, SLOTTED |
| 51216-12 | DOWEL 1.0 X 1.5 |
| 51222-05-12 | PIN. SPIRAL (RLA 500 TON) |
| 50012-20-C8D | SCREW, CAP-HEX HD |
| 30151953 | HOUSING, HYD DRIVE/SHOT PIN |
| 30151953-LT | HOUSING, HYD DRIVE/SHOT PIN |
| 30156250 | GEAR, COMPOUND, 40X25 |
| 30151960 | SHAFT, COMPOUND GEAR PH-100 |
| 30151960-LT | SHAFT, COMPOUND GEAR PH-100 |
| 30173958 | SHOT PIN |
| 30173958-LT | SHOT PIN |
| 110061-326 | SEAL PISTON |
| 30151951 | SLEEVE, SHOT PIN |
| 110056 | ROD SEAL ASSEMBLY,1.5 BORE |
| 51300-226-B | O-RING |
| 30151961 | FLANGE, BUSHING, SHOT PIN, PH-100 |
| 30151954 | BEARING, RADIAL LIGHT |
| 30156256 | GEAR, DRIVE |
| 53500-225 | RING, RETAINING, INTERNAL |
| 30151955 | RETAINER, BEARING, PH-100 |
| 30158011 | HYD MOTOR, MODIFIED LOW SPEED HIGH TORQUE |
| 30151959 | RETAINER, PIN |
| 94522-IEN | CARTRIDGE VALVE RELIEF TDS9S |
| 56555-6-6-S | VARCO BJ CONNECTOR |
| 93024-6JIC | FITTING, TEST POINT, 1/4 NPT |
| 50005-26-C | CAPSCREW |
| 30152190 | MANIFOLD ASSY (NO SOLENOID VALVE) |
| 30152190-1 | MANIFOLD ASSY (24 VDC Eexd VALVE) |
| 30152190-2 | MANIFOLD ASSY (24 VDC UL VALVE) |
| 30152190-3 | MANIFOLD ASSY (COVER PLATE) (NO SOLENOID VALVE) |
| 30152190-4 | MANIFOLD ASSY (COVER PLATE) (NO SOLENOID VALVE) |
| 30152190-SS | MANIFOLD ASSY (STAINLESS) |
| 30114855-7500 | S-PIPE, LH, WELDMENT, 7500 PSI (OUTSIDE GUARD) |
| 117063-7500 | S-PIPE, RH, WELDMENT, 7500 PSI (OUTSIDE GUARD) |
| 116376 | S-PIPE, WELDMENT (HERCULES) |
| 30114855 | S-PIPE, LH WELDMENT, 5000 PSI (OUTSIDE GUARD) |
| 117063 | S-PIPE, RH WELDMENT, 5000 PSI (OUTSIDE GUARD) |
| 114840 | MOUNT, S-PIPE LH (OUTSIDE GUARD) |
| 117061 | MOUNT, S-PIPE RH (OUTSIDE GUARD) |
| 108870-1 | MOUNT, S-PIPE-BASE |
| 108870-2 | MOUNT, S-PIPE-TOP |
| 92426 | RUBBER, S-PIPE |
| 30123290 | ASSEMBLY, WASH PIPE |
| M614002641 | ASSY, PLUG, 3" FIG 1002 |
| 91923 | SEAL RING, 3" FIG 1002 |
| 78002 | CLAMP, SERVICE LOOP BRACKET |
| 81158 | WING NUT, 4" FIG 1003 |
| 114833 | SEAL RING, 4" FIG 1002 |
| 107714 | MOUNT, COMPOSITE CABLE |
| 56541-32 | KIT, FLANGE |
| 116411 | BRACKET, SERVICE LOOP/S-PIPE |
| 50008-16-C5D | SCREW, CAP-HEX HEAD |
| 50012-13-C5D | SCREW, CAP-HEX HEAD |
| 50012-30-C5D | SCREW, CAP-HEX HEAD |
| 50008-30-C5D | SCREW, CAP-HEX HEAD |
| 114093-75 | ELBOW, S-PIPE, 5" FIG 1002, FEMALE |
| 117679 | MALE SUB, 4" FIG 1002, FEMALE |
| 84617 | ELBOW, S-PIPE, 4" FIG 1002, FEMALE |
| 81153 | ELBOW, S-PIPE, 4" API LPT END, FEMALE |
| 30123563 | BOX, PACKING ASSY, 3" WASH PIPE |
| 123284 | NUT, 3" WASH PIPE |
| 30123289 | PIPE, WASH-3" BORE |
| 30123289-C88 | PIPE, WASH-3" BORE, C88 |
| 30123288 | RING, HOLDING, 3" WASH PIPE |
| 30123562 | RING, SNAP |
| 30123564 | SCREW, SOCKET HD-DOG NOSE |
| 30123287 | SPACER, LOWER, 3" WASH PIPE |
| 30123286 | SPACER, MIDDLE, 3" WASH PIPE |
| 123285 | SPACER, UPPER, 3" WASH PIPE |
| 30150084 | WRENCH, WASHPIPE |
| 123292-2 | PACKING SEAL KIT (5 PER SET) |
| 123292-3 | PACKING SEAL KIT (5 PER SET) |
| 51300-348-F | O-RING |
| 86268 | GREASE, GE-MTR (SHELL/EXXON) |
| 53219-1 | FITTING, GREASE- STRAIGHT EXT. |
| 56005-1 | DELETED |
| 3013289-TC | DELETED |
| 80-506-100 | SYSTEM, BLAK JAK WASHPIPE CARTRIDGE WITH HANGER AND TOOLS, 5000 PSI |
| 80-506-100S | SPARE CARTRIDGE, BLAK JAK WASHPIPE P-TYPE |
| 61938641 | WASHPIPE, WITH SNAP RING P-TYPE |
| 703429G3U | SET, WASHPIPE PACKING 5 RINGS WITH 2 THICK O-RINGS |
| 80506100K | STANDARD REBUILD KIT (INCLUDES ITEM 9,10,12,14,18,19) |
| 80506100KS | SEAL REBUILD KIT (INCLUDES ITEM9,10,12) |
| 80506100KA | COMPLETE REBUILD KIT (INCLUDES ITEM 8,9,10,14,16,18,19,20) |
| 80-50-6017 | WASHPIPE HOLDING RING |
| 7817600348 | O-RING THICK |
| 99609245 | O-RING THIN |
| 80-50-6015 | UPPER WASHPIPE PACKING ADAPTER RING THREADED |
| 612984 | PACKING RING |
| 80-506-014 | UPPER WASHPIPE NUT |
| 80-506-001 | HOUSING, LOWER GLAND |
| 661010020 | GREASE FITTING |
| 80-506-010 | NUT, LOWER GLAND |
| 80-506-004 | UPPER WASHPIPE PACKING SPACER RING |
| 80-506-005 | MIDDLE WASHPIPE PACKING SPACER RING |
| 80-506-006 | LOWER WASHPIPE PACKING ADAPTER RING THREADED |
| 80-506-037 | HANGER ASSY (INCLUDES ONE SPANNER BAR W/ LANYARD) |
| 80-506-020 | SPANNER BAR |
| 80-506-031 | SPANNER TOOL |
| 80-506-027 | ASSEMBLY FIXTURE |
| 120887 | GUARD, MOTOR HOUSING |
| 30171318-500 | WELDMENT SUPPORT, UPPER GUARD/WEDGE |
| 30171318-501 | WELDMENT SUPPORT, UPPER GUARD/WEDGE |
| 117089 | SUPPORT, LOWER |
| 117089-395 | SUPPORT, LOWER |
| 30177155 | SCREW, CAP-HEX HD |
| 121483 | LABEL, LINK INSTALLATION |
| 51402-12 | COTTER PIN (1/8 NOM) |
| 110564-1SEP | ACCUMULATOR, HYDRO-PNEUMATIC 2" |
| 110564-1 | ACCUMULATOR, HYDRO-PNEUMATIC 2" |
| 110563-1CE | ACCUMULATOR, HYDRO-PNEUMATIC 4" |
| 110563-1 | ACCUMULATOR, HYDRO-PNEUMATIC 4" |
| 110562-1CE | ACCUMULATOR, HYDRO-PNEUMATIC 6" |
| 110562-1 | ACCUMULATOR, HYDRO-PNEUMATIC 6" |
| 30115918 | ADAPTER, PUMP INLET/DRAIN |
| 55913-12 | CAP, DUST-PLASTIC (QD) |
| 94270-6 | CLAMP, DBL 1/2" TUBE |
| 94270-4 | CLAMP, DBL 3/8" TUBE |
| 56501-12-12-S | CONNECTOR EXT PIPE/37 |
| 56501-4-4-S | CONNECTOR, EXT PIPE/37 |
| 56524-8-8-S | CONNECTOR, EXT PIPE/37 |
| 56529-16-16S | CONNECTOR, O-RING BOSS/37 |
| 56529-6-6-S | CONNECTOR, O-RING BOSS/37 |
| 56551-16-12S | CONNECTOR, O-RING BOSS/INT PIPE |
| 940315-20 | CONNECTOR, STAUFF #TCM20 |
| 56502-16-12S | ELBOW, 45 EXT PIPE/37 |
| 56702-12-12S | ELBOW, 90 EXT PIPE |
| 56506-16-16S | ELBOW, 90 EXT PIPE/37 |
| 56506-4-4-S | ELBOW, 90 EXT PIPE/37 |
| 56555-4-4-S | ELBOW, 90 EXT PIPE/37 |
| 56522-6-6-S | ELBOW, BULKHEAD 37/37 |
| 56519-12-6-S | ELBOW, O-RING BOSS/37 |
| 56519-16-12S | ELBOW, O-RING BOSS/37 |
| 56519-4-4-S | ELBOW, O-RING BOSS/37 |
| 56519-8-6-S | ELBOW, O-RING BOSS/37 |
| 56519-8-8-S | ELBOW, O-RING BOSS/37 |
| 30111013 | FILTER, ASSY, 60 MICRON, GEAR OIL |
| 30173216 | FILTER, HYDRAULIC |
| 79255 | GROMMET |
| 59046P08X036 | HOSE ASSY, BRAKE UNION |
| 59024P230030 | HOSE ASSY, PF TO PUMP MOTOR |
| 30124191-500 | HOSE ASSY, PUMP PRESSURE/MANIFOLD |
| 56541-12 | KIT, FLANGE |
| 56541-16 | KIT, FLANGE |
| 30171993 | KIT, TUBE ASSY, TDS-11SA |
| 121403-DWG | PACKAGE, HYDRAULIC, TDS-11SA |
| 87196-6-S | PLUG, SAE-6, O-RING, .562-18, HEX SOCKET |
| 53002-2-C | PLUG, PIPE-SQUARE HEAD |
| M854000259 | PRE-FILL VALVE ASSEMBLY |
| 56700-12-8-S | REDUCER PIPE INT/EXT |
| 56516-12-6-S | REDUCER, INT 37/37 |
| 56556-12-6-S | REDUCER, O-RING, BOSS |
| 56556-16-12S | REDUCER, O-RING, BOSS |
| 56556-16-8-S | REDUCER, O-RING, BOSS |
| 56700-24-16S | REDUCER, PIPE-EXT/INT |
| 50006-06-C5D | SCREW, CAP-HEX HEAD (UNC) |
| 50006-28-C5D | SCREW, CAP-HEX HEAD (UNC) |
| 55008-12-C5D | SCREW, CAP-HEX HEAD (UNF-2A) |
| 56160-12-12S | TEE, 37/37/ INT PIPE |
| 56530-12-12S | TEE, 37/37/O-RING BOSS |
| 56513-12-S | TEE, BULKHEAD UNION 37 |
| 56162-4-4-S | TEE, PIPE, EXT/INT/INT |
| 56706-12-S | TEE, PIPE, EXT/INT/INT |
| 114083 | TUBE ASSY, MANIFOLD/CASE DRAIN |
| 53300-523 | TY-RAP |
| 53300-527 | TY-RAP |
| 53300-529 | TY-RAP |
| 55909-12-12 | VALVED NIPPLE, QD/EXT PIPE |
| 30125103 | ASSY, TUBE, LUBRICATION OUT |
| 30171975 | ASSY, TUBE, MANIFOLD/SHOT PIN |
| 30184037 | ASSY, TUBE, TDS-11SA |
| 30178403 | TUBE ASSY |
| 30179002 | TUBE ASSY |
| 118410 | TUBE ASSY, ACCUMULATOR / LOAD STEM |
| 30172005 | TUBE ASSY, ACCUMULATOR / MANIFOLD (3/8") |
| 116690 | TUBE ASSY, C'BAL ACCUM / MANIFOLD |
| 121511 | TUBE ASSY, FILTER / QUICK COUPLER |
| 119028 | TUBE ASSY, HEAT EXCHANGER / FILTER |
| 30172006 | TUBE ASSY, IBOP PRESS SW/MANIFOLD (1/4") |
| 30125100 | TUBE ASSY, LINK ADAPTER LIFT |
| 113974 | TUBE ASSY, LUBE MOTOR/MANIFOLD |
| 114090-502 | TUBE ASSY, LUBE- PUMP-MANIFOLD /FILTER |
| 114090 | TUBE ASSY, LUBE- PUMP-MANIFOLD /FILTER |
| 30125104 | TUBE ASSY, LUBRICATION IN |
| 118408 | TUBE ASSY, MANIFOLD / BRAKE |
| 118408-500 | TUBE ASSY, MANIFOLD /LOAD STEM |
| 115426 | TUBE ASSY, MANIFOLD/ LOAD STEM |
| 118405 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 30115421 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 115422 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 115423 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 117570 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 115425 | TUBE ASSY, MANIFOLD/LOAD STEM |
| 30171974 | TUBE ASSY, MANIFOLD/SHOT PIN |
| 121511-500 | TUBE ASSY, OIL FILTER / MANIFOLD |
| 113984 | TUBE ASSY, PRE-FILL / BULKHEAD |
| 119029 | TUBE ASSY, PRE-FILL/FILTER |
| 113988 | TUBE ASSY, PRESS. SWITCH / AIR DUCT |
| 121512 | TUBE ASSY, QUICK CONNECT/ MANIFOLD |
| 113985 | TUBE ASSY, RESERVOIR/PRE-FILL MANIFOLD |
| 30125099 | TUBE ASSY, SHOT PIN |
| 30113982-500 | TUBE, DRAIN, RESERVOIR, ASSY, TDS11 |
| 30113982 | TUBE, DRAIN, RESERVOIR, ASSY, TDS11 |
| 118409-500 | TUBE, LINE/HE, ASSY, TDS11 |
| 118409 | TUBE, LINE/HE, ASSY, TDS11 |
| 30114085-500 | TUBE, PRE-FILL/MANIFOLD, ASSY,TDS9 |
| 30114085 | TUBE, PRE-FILL/MANIFOLD, ASSY,TDS9 |
| 30114086-500 | TUBE, PUMP/RESERVOIR TDS11 |
| 30114086 | TUBE, PUMP/RESERVOIR TDS11 |
| 117091-500 | TUBE, RESERVOIR/ PUMP, ASSY, TDS11 |
| 117091 | TUBE, RESERVOIR/ PUMP, ASSY, TDS11 |
| M854000258-2 | MANIFOLD, PRE-FILL VALVE |
| 30107236-1DN | SEQUENCE VALVE CARTRIDGE (SCCA-LDN) |
| 30176409-4XN | VALVE, LOGIC, NORMALLY OPEN (LOJO-XDN) |
| 109302-130NC | VALVE, FLOW CONTROL, FIXED SETTING (CNCC-XCN-047) |
| 93024-4SAE | FITTING, TEST, SAE -4 SMK-7/16 UNF |
| 56519-6-6-S | ELBOW, 90, 37 O-RING |
| 56519-16-12-S | ELBOW, 90, 37 O-RING |
| 56519-12-12-S | ELBOW, 90, 37 O-RING |
| 56529-12-12-S | CONNECTOR, O-RING BOSS /37 |
| 87196-2-S | PLUG, STRAIGHT THD, HEX W/O-RING |
| 87196-4-S | PLUG, STRAIGHT THD, HEX W/O-RING |
| 112809-06 | CAP, PLASTIC, -6 JIC |
| 112809-12 | CAP, PLASTIC, -12 JIC |
| 114174 | MANIFOLD ASSY |
| 114113-2 | PUMP / MOTOR ASSY |
| 120997-1 | BRKT, SERVICE LOOP – LEFT HAND |
| 127652-501 | BRACKET, CONNECTOR-RIGHT HAND |
| 127652-502 | BRACKET, CONNECTOR-LEFT HAND |
| 120997 | BRKT, SERVICE LOOP-RIGHT HAND |
| 76841 | PRESSURE SWITCH, AIR |
| 83095-1 | PRESSURE SWITCH, IBOP |
| 87541-1 | PRESSURE SWITCH, OIL |
| 110143 | PLATE, MOUNTING-J-BOX/MANIFOLD |
| 115202 | NAMEPLATE, CONNECTOR WARNING |
| 115720 | LABEL, CONNECTOR |
| 115909 | BRACKET, MOUNTING, CABLE TRAY |
| 115910 | BRACKET, MOUNTING, CABLE TRAY |
| 115911 | CABLE TRAY |
| 116427 | STUD, GROUNDING |
| 118866 | EARTHING BAR ASSY |
| 118993 | CABLE, 70mm2 YELLOW W/ GREEN TRACER |
| 124994 | J-BOX ASSEMBLY |
| 127386 | 3M POTTING COMPOUND |
| 30182634 | ELEC / MANIFOLD SUB-ASSY |
| 110022-1B | CONNECTOR, SINGLE PIN, POWER, BLACK |
| 110022-1R | CONNECTOR, SINGLE PIN, POWER, RED |
| 110022-1W | CONNECTOR, SINGLE PIN, POWER, WHITE |
| 119888-100-38 | CABLE TRAY (3/16 SS 4'' X 38'' VENTILATED) |
| 122718-01-20 | CABLE, PIGTAIL ASSY COMP (42 COND) |
| 124459-01-20 | CABLE, PIGTAIL ASSY COMP (18 COND) |
| 129991-07 | GLAND, EEXE ARMOURED CABLE, 50MM |
| 53219-3 | FITTING, GREASE-STRAIGHT EXTENDED |
| 53908-B | NIPPLE, CLOSE |
| 56600-12-8 | BUSHING, REDUCING, ELECTRICAL |
| 56600-16-12 | BUSHING, REDUCING, ELECTRICAL |
| 56606-8 | ELBOW, CAPPED |
| 56609-11 | TERMINAL WIRE RING |
| 56609-25 | TERMINAL, WIRE-RING |
| 56611-8 | ELBOW, 45' INT ELECT |
| 56625-2.5-04 | CABLE, SHIPBOARD-MULTICORE |
| 56626-03 | CABLE, SHIPBOARD-TWISTED/SHIELDED |
| 83444-01 | GLAND, EEXE ARMOURED CABLE, 20MM |
| 83444-03 | GLAND, CABLE, ARMORED, 20MM |
| 83444-05 | GLAND, EEXE ARMOURED CABLE, 25MM |
| 83444-07 | GLAND, CABLE, ARMORED, 32MM |
| 86625-01 | GLAND, CABLE-JACKETED (UL) (1/2 NPT) |
| 86625-02 | GLAND, CABLE-JACKETED (UL) |
| 86871-20 | WASHER, NYLON SEALING |
| 86871-25 | WASHER, NYLON SEALING 25 MM |
| 86871-32 | WASHER, NYLON SEALING |
| 86871-50 | WASHER, NYLON SEALING |
| 86872-20-S | LOCKWASHER, INTERNAL STAR (20MM) SS |
| 86872-25-S | LOCKWASHER, INTERNAL STAR (25MM) |
| 86872-32-S | LOCKWASHER, INTERNAL STAR |
| 86872-50-S | LOCKWASHER, INTERNAL STAR |
| 87074-06B | WASHER, LOCK, STAR |
| 87074-8-B | WASHER, LOCK – STAR (BRASS) (1/2) |
| 94872-3 | LUG, CONNECTOR, COPPER |
| Z6000.8 | LOCKWIRE Ø.031 |
| 78317-20 | LOCKNUT |
| 78317-25 | LOCKNUT 25MM |
| 78317-32 | LOCKNUT |
| 78317-50 | LOCKNUT |
| 78725-04 | FERRULE |
| 56625-1.5-03 | CABLE, SHIPBOARD-MULTICORE |
| 15193 | HPU PUTTY, ELECTRICAL INSULATION |
| 78733 | CLAMP, SUPPORT |
| 50004-10-C5D | SCREW, CAP-HEX HEAD |
| 50004-14-C5D | SCREW, CAP-HEX HEAD |
| 50004-8-C5 | SCREW, CAP-HEX HEAD |
| 50004-8-C5D | SCREW, CAP-HEX HEAD |
| 50005-10-C5 | SCREW, CAP-HEX HEAD |
| 50005-4-C5D | SCREW, CAP-HEX HEAD |
| 50010-44-C5D | SCREW, CAP-HEX HEAD |
| 50010-52-C5D | SCREW, CAP-HEX HEAD |
| 50182-8-03 | SCREW, CAP-BUTTON HEAD |
| 50206-B | NUT, HEX – BASS (3/8-16) UNC |
| 50606-8-C | SCREW, CAP – FLAT HEAD |
| 50804-R-C | WASHER, FLAT-REGULAR |
| 50810-R-C | WASHER, FLAT (5/8) |
| 50910-S | WASHER, LOCK – REGULAR |
| 51804-C | NUT, HEX-SELF LKG (UNC-2B) |
| 51805-C | NUT, HEX-SELF LOCKING (UNC-2B) |
| 53301-10-6 | SCREW, DRIVE-TYPE U |
| 107783-5C11R | PUMP, HYD. VANE, 1.0 CU. IN./IN. |
| 109542 | PUMP, HYD. PISTON, PRES. COMP. |
| SEE CHART | AC-MOTOR, 10 HP (EXPLOSION PROOF) |
| 112640 | ADAPTER, PUMP/MOTOR |
| 110023 | FLEX COUPLING |
| 15230 | ROTATION ARROW |
| 51300-152-B | O-RING |
| 50006-24-C8D | SCREW, CAP HEX-HEAD |
| 50070-025F06 | SCREW, CAP HEX-HEAD |
| 50806-N-C | WASHER, FLAT, 3/8" |
| 51007-C | WASHER, LOCK, HEAVY |
| 53301-4-4 | DRIVE SCREWS |
| 55004-4-C5D | SCREW, CAP HEX-HEAD |
| M105698 | PUMP COUPLER |
| 109755 | 460 V, 60 HZ, 3 PHASE |
| 109755-1 | 550 V, 60 HZ, 3 PHASE |
| 109755-2 | 575 V, 60 HZ, 3 PHASE |
| 109547-2 | MANIFOLD, TDS-9 (MACHINING) |
| 127908-J2 | SOLENOID, VALVE, 3-POS 24 VDC |
| 127908-D2 | SOLENOID VALVE, 2-POS., 24VDC |
| 30171921 | REWORK MANUAL VALVE, 3-POS |
| 93667-M11 | CAVITY PLUG, T-11A SHORT |
| 94520-1NN | RELIEF VALVE |
| 94534-1CXN | LOGIC CARTRIDGE |
| 94536-14N | CHECK VALVE |
| 94536-230N | CHECK VALVE |
| 98402-800D | PILOT-TO-CLOSE CHECK VALVE |
| 99353-1AN | DIFFERENTIAL UNLOADING VALVE |
| 107028-1ANB | PILOT-TO-OPEN CHECK VALVE |
| 107029-175N | RELIEF VALVE, VENTABLE |
| 107031-1AN / P514000063-1AN | VALVE, RELIEF, PILOT OPERATED, BALANCED PISTON |
| 93667-M13 | CAVITY PLUG, T-13A SHORT |
| 109858-1AN | REDUCING/RELIEVING VALVE |
| 111664-1EN | RELIEF VALVE, LOW FLOW |
| 93024-6SAE | TEST FITTING, SAE-6 |
| 93018-14 | ORIFICE PLUG, 10-32x.055 |
| 110844-18 | ORIFICE PLUG, 1/4 NPT X.071 |
| 56531-4-S / 87196-4-S | SAE, J514-4 HEX SOCKET PLUG |
| 87196-8-S | SAE, J514-8 HEX SOCKET PLUG |
| 87196-10-S | SAE, J514-10 HEX SOCKET PLUG |
| 53000-1-C | 1/16 NPT HEX SOCKET PLUG |
| 56544-4-S | CAP, FEMALE, 37 SEAT |
| 56544-6-S | CAP, FEMALE, 37 SEAT |
| 56544-12-S | CAP, FEMALE, 37 SEAT |
| 50103-16-B | CAPSCREW, HEX SOC HD, # 10-24UNC x 2.00 |
| 96079-A | COVER, PLATE D03 |
| 99838-1 | COVER, SUN CARTRIDGE, SERIES 1 |
| 53200-7471 | PRIMER ACTIVATOR |
| 110181 | NAMEPLATE, C' BALANCE MODE |
| 82226 | SEALANT, TAPERED PIPE |
| 56519-10-12S | ELBOW |
| 56519-10-8-S | ELBOW |
| 56519-4-4S | ELBOW |
| 56519-6-4-S | ELBOW |
| 56519-4-6-S | ELBOW |
| 128694-6-031 | FLOW CONTROL, -06 MORB / MJIC,.031 ORIFICE |
| 56444-8-S | CAP, JIC 1/2'' |
| 56529-4-6-S | CONNECTOR |
| 93018-18 | ORIFICE PLUG, 10-32 X,071 |
| 56518-6-6-S | -6 FJIC / -6 MJIC, ELBOW |
| 50103-10-B | SOCKET CAP SCREW 10-24 X 1 -1/4 |
| 124993 | J-BOX (MACHINING) |
| 78927-6 | SUPPORT RAIL |
| 78927-3 | SUPPORT RAIL |
| 123294-3 | TERMINAL ASSEMBLY |
| 123294-2 | TERMINAL ASSEMBLY |
| 30158431 | BREATHER DRAIN |
| 123220 | TERMINAL ASSEMBLY (GND. BUS BAR) |
| 96371 | SCREW, FLAT HEAD (METRIC) |
| 78916 | FIXING NUT AND SCREW (METRIC) |
| 50067-040-F-07 | SCREW, CAP-HEX (METRIC) |
| 50803-N-S | WASHER, FLAT |
| 50649-60 | SCREW |
| 30173254-08 | FILLISTER HEAD SCREW, DRILLED |
| Z6001.8 | LOCKWIRE, 0.032" |
| 117821 | TORQUE WRENCH ASSEMBLY |
| 119455 | PIN, CRANK |
| 119545 | CRANK ASSEMBLY, LINK TILT |
| 125097 | TUBE ASSY, LINK ADAPTER/MANIFOLD |
| 125094 | TUBE ASSY, LINK ADAPTER/MANIFOLD |
| 119592 | CYLINDER, HYDRAULIC ASSEMBLY |
| 119387 | PIN, PIPE HANDLER |
| 59024P170023 | HOSE ASSY, IBOP CYL, OPEN |
| 59043P170023 | HOSE ASSY, IBOP CYL, CLOSE |
| 114212 | CLIP, WIRE ROPE, 3/16" |
| 110042 | SHELL, ACTUATOR, IBOP |
| 98898 | CRANK ASSEMBLY, IBOP |
| 107052 | LOCK TAB |
| 118947 | BAR, RETAINING |
| 119123 | LINK |
| 56416-32-C | CLEVIS PIN |
| 50816-R-C5 | WASHER, FLAT-REGULAR |
| 118463-2 | MANIFOLD, LINK TILT CYLINDER |
| 123685 | BRACKET-MOUNTING, LINK TILT MANIFOLD |
| 51425-20-S | PIN, COTTER |
| 120157 | HOSE ASSY, HYDRAULIC CYL.-CRANK ASSY |
| 120161 | HOSE ASSY, HYDRAULIC CYL.-CRANK ASSY |
| 56416-28-C | CLEVIS PIN |
| 114196-1 | WIRE ROPE ASSY |
| 56519-12-125 | ELBOW, O-RING BOSS/37 |
| 120165 | CLAMP, LINK TILT, 500 TON |
| 119122 | CLAMP, LINK TILT, 350 TON |
| 120164 | CLAMP, LINK TILT, 250 TON |
| 122367 | U-BOLT, 500 TON |
| 119139 | U-BOLT, 350 TON |
| 120162 | U-BOLT, 250 TON |
| 110103-500 | IBOP, UPPER |
| 114706-500 | IBOP, LOWER |
| 110103-502 | IBOP, UPPER, H2S (HES TRIM) |
| 114706-502 | IBOP, LOWER, H2S TRIM |
| 112848 | TOOL JOINT LOCK |
| 117811 | SAVER SUB, NC50 (LONG) |
| 129089-375 | SAVER SUB, 6 5/8, HT55-375 (SHORT / REG) |
| 117812 | SAVER SUB, NC46 (LONG) |
| 129089 | SAVER SUB, HT55-400 (SHORT) |
| 118952 | SAVER SUB, NC40 (LONG) |
| 118953 | SAVER SUB, HT40 (LONG) |
| 118953-1 | SAVER SUB, HT40 (SHORT/REG) |
| 118954 | SAVER SUB, NC38 (LONG) |
| 118954-1 | SAVER SUB, NC38 (SHORT/REG) |
| 118955 | SAVER SUB, NC31 (LONG) |
| 118955-1 | SAVER SUB, NC31 (SHORT) |
| 118956 | SAVER SUB, NC26 (LONG) |
| 118956-1 | SAVER SUB, NC26 (SHORT) |
| 123114 | GUIDE, STABBING, 7.00-7.50 OD TOOL JOINT |
| 118250 | GUIDE, STABBING, 4.00-5.125 OD TOOL JOINT |
| 118249 | GUIDE, STABBING, 5.20-6.63 OD TOOL JOINT |
| 118957 | GUIDE, STABBING, NC26 TOOL JOINT |
| 122109 | JAW ASSY, 6.38-7.50 OD TOOL JOINT |
| 80492 | JAW ASSY, 4.00-5.125 OD TOOL JOINT, NC31-NC38 |
| 85786-2 | JAW ASSY, 5.25-6.63 OD TOOL JOINT, NC40 – NC50 |
| 118958 | JAW ASSY, 3.00-4.00 OD TOOL JOINT, NC26 |
| 50108-18-C | CAP SCREW, HEX HD DRILLED |
| 117941 | CYLINDER ASSEMBLY, CLAMP |
| 117822 | PIPE HANDLER, TORQUE ARRESTOR |
| 118511 | MANIFOLD, CLAMP CYLINDER |
| 117853 | YOKE, IBOP ACTUATOR |
| 118510 | CYLINDER ASSEMBLY, IBOP ACTUATOR |
| 117869-500 | END CAP, PIPE HANDLER |
| 110083 | SPRING |
| 50832-N-C | SPACER, SPRING |
| 110074 | PIN, PIVOT |
| 118336 | PIN, PIVOT |
| 118531 | PIN, PIVOT |
| 71847 | ROLLER |
| 118844-12-16 | BEARING, FIBREGLIDE JOURNAL |
| 118844-22-30 | BEARING, FIBREGLIDE JOURNAL |
| 118844-16-16 | BEARING, FIBREGLIDE JOURNAL |
| 119597-1 | SLEEVE, SPRING |
| 50822-R- C | FLATWASHER |
| 51403-16 | PIN, COTTER |
| 50812-R- C | FLATWASHER |
| 50005-20- C5D | SCREW, CAP, HEX HD. |
| 50016-18- C5D | SCREW, CAP, HEX HD. |
| 51016-C | WASHER, LOCK-HEAVY |
| 50914-C | WASHER, LOCK-REGULAR |
| 55214-C | NUT, HEX-STANDARD |
| 118021 | GATE |
| 118019 | BODY, CLAMP CYLINDER |
| 11075 | CYLINDER HEAD |
| 12820 | PISTON |
| 117991 | PIN, HINGE |
| 72221 | RING, WIPER |
| 72219 | SEAL, PISTON |
| 72220 | SEAL, ROD |
| 107303-1-8 | FLANGE PROTECTOR, SAE J519 |
| 118368 | STABILIZER ASSY, FRONT |
| 118367 | STABILIZER ASSY, REAR |
| 123313 | RETAINER, HINGE PIN |
| 79179 | SPRING, DIE |
| 110152 | BUSHING, WEAR SST |
| 117989 | SCREW, HEX-HD, DRILLED SHANK |
| 50516C | NUT, HEX-SLOTTED |
| 50816-N-5C | WASHER |
| 51403-14-C | PIN, COTTER |
| 30157288 | TORQUE ARRESTER ASSEMBLY |
| 30158189 | CRANK ASSEMBLY, LINK TILT |
| 30158164 | PIN, CRANK |
| 30170445 | LINK 1, COLLAPSIBLE |
| 30170446 | LINK 2, COLLAPSIBLE |
| 125098 | TUBE ASSEMBLY, LINK ADAPTER / MANIFOLD |
| 30119592 | CYLINDER, HYDRAULIC ASSEMBLY |
| 30125094 | TUBE ASSEMBLY, LINK ADAPTER / MANIFOLD |
| 30125097 | TUBE ASSEMBLY, LINK ADAPTER / MANIFOLD |
| 30170045 | PIN, RETAINER, COLLAPSIBLE LINK |
| 118868-6 | SHACKLE, ANCHOR |
| 120162 (TBD) | U-BOLT, 250 TON |
| 123059-2-108 | SLING, ROPE, WIRE |
| 131085-024 | SLEEVE, NYLON |
| 50006-08-C5D | SCREW, CAP-HEX HEAD |
| 50006-38-C5D | SCREW, CAP HEX HD |
| 50412-C | NUT, HEX-HEAVY (3/4-10) |
| 50514-C | NUT, HEX-SLOTTED (7/8-9) |
| 50814-N-C | WASHER, FLAT |
| 50820-N-C | WASHER, FLAT |
| 51008-C | WASHER, LOCK-HEAVY (1/2) |
| 51012-C | WASHER, LOCK-HEAVY (3/4) |
| 51402-10-S | PIN, COTTER (1/8 X 1.25) |
| 51403-20 | PIN, COTTER |
| 51435-20-S | PIN, COTTER (5/32 X 2.50) |
| 53300-525 | TIE, CABLE |
| 59024P170021 | HOSE ASSEMBLY, IBOP CYLINDER |
| 59024P170025 | HOSE ASSEMBLY, IBOP CYLINDER |
| 59024P230046 | HOSE ASSEMBLY, HYDRAULIC CYLINDER LINK TILT |
| 59043P230031 | HOSE ASSEMBLY, HYDRAULIC CYLINDER LINK TILT |
| 59043P230042 | HOSE ASSEMBLY, HYDRAULIC CYLINDER LINK TILT |
| 59043P23G028 | HOSE ASSEMBLY, HYDRAULIC CYLINDER LINK TILT |
| 59044P230073 | HOSE ASSEMBLY, CLAMP, PISTON |
| 59044P230074 | HOSE ASSEMBLY, CLAMP, ROD |
| 51435-16 | PIN, COTTER (5/32 X 2.00) |
| 30172154 | PIN, CYLINDER MOUNTING |
| 103141-7 | CLEVIS |
| 119416 | CYLINDER, HYDRAULIC |
| 114706-501 | VALVE ASSEMBLY |
| 114706-503 | VALVE ASSEMBLY |
| 114705 | BODY, IBOP |
| 89141-7 | CRANK, OPER.-RH |
| 89453-7 | CRANK, OPER.-RH |
| 89141-8 | SEAL, CROWN |
| 89453-8 | SEAL, CROWN |
| 90441-7 | SLEEVE, CRANK |
| 89141-11 | O-RING |
| 89453-11 | O-RING |
| 89141-12 | BACK-UP RING |
| 89453-12 | BACK-UP RING |
| 30177592 | SET, SEAT/BALL |
| 30177892 | SET, SEAT/BALL (H2S) |
| 89141-9 | SPRING, WAVE |
| 89453-9 | SPRING, WAVE |
| 89141-3 | O-RING |
| 89141-13 | BACK-UP RING |
| 89453-13 | BACK-UP RING |
| 90441-9 | O-RING |
| 89453-16 | O-RING |
| 90441-10 | BACK-UP RING |
| 89453-17 | BACK-UP RING |
| 91137-12 | NYLON PLUG |
| 89141-1 | RETAINING RING |
| 89453-1 | RETAINING RING (H2S) |
| 77369-6 | THREAD PROTECTOR-PIN |
| 114792 | BODY, IBOP (NAM) |
| 114791 | BODY, IBOP (GLAND POCKET ONLY) |
| 99498-2 | REPAIR KIT – COMPLETE |
| 99498-1 | REPAIR KIT – SOFT SEALS |
| 99503-2 | REPAIR KIT – COMPLETE |
| 99503-1 | REPAIR KIT – SOFT SEALS |
| 79489-14 | PULLER – SEAT |
| 89141-18 | WRENCH – NUT |
| 110103-501 | VALVE ASSY. |
| 110118 | CRANK, OPER-L.H. |
| 110102 | BODY, IBOP |
| 30114902 | CRANK, OPER-L.H. |
| 65060690 | SLEEVE, CRANK |
| 65060792 | SET, SEAT/BALL |
| 65060794 | SET, SEAT/BALL |
| 89453-3 | O-RING |
| 65060625 | STABILIZER, SEAL RING |
| 96439 | SEAL, U-CUP |
| 96439-1 | SEAL, U-CUP |
| 91441-10 | BACK-UP RING |
| 91137-10 | PLUG, PRESSURE |
| 77369-5 | THREAD PROTECTOR – 6-5/8 |
| 114859 | REPAIR KIT- COMPLETE |
| 114860-2 | REPAIR KIT- COMPLETE |
| 114859-1 | REPAIR KIT- SOFT SEALS |
| 114860-1 | REPAIR KIT- SOFT SEALS |
| 98899 | ARM, CRANK (MACHINING) |
| 98897 | CRANK HOUSING (MACHINING) |
| 79824 | CAM FOLLOWER |
| 99168 | SPACER |
| 79825 | ROLLER BEARING |
| 51300-220-B | O-RING |
| 30158188 | CRANK, ASSEMBLY |
| 118844-16-24 | BUSHING, FIBREGLIDE |
| 118172-2 | MANIFOLD, LINK TILT CYLINDER (ALUMINUM) |
| 118172-BSC | MANIFOLD, LINK TILT CYLINDER (STEEL) |
| 118172-1 | MANIFOLD, LINK TILT CYLINDER (S. S.) |
| 30173386 | VALVE, COUNTERBALANCE (CBCA-LHN) |
| 93547-1B30N | CHECK VALVE, PILOT TO OPEN (CXCB-XCN) |
| 94042-36 | ORIFICE, 1/8NPT X 0.142 |
| 93018-08 | ORIFICE. #10-32UNF X 0.031 |
| 56529-8-8-S | CONNECTOR, O-RING BOSS/37', ½'' |
| 112809-08 | CAP, SHIPPING, THREADED, -8 |
| 53200-545 | LOCTITE, HYDRAULIC |
| 112809-04 | CAP, SHIPPING, THREADED, -4 |
| 30157287 | CLAMP CYLINDER ASSEMBLY |
| 30157226 | TORQUE ARRESTOR, PIPE HANDLER |
| 125594 | CYLINDER ASSY, HYD, IBOP ACTUATOR |
| 30157225 | YOKE, IBOP ACTUATOR |
| 30157308 | SPRING |
| 30157294 | BOTTOM PLATE |
| 121979 | TRUNNION BUSHING, CYL MOUNT |
| 30157292 | POST, SPRING |
| 30158766-1 | PIN, PIVOT, YOKE |
| 30157318-1 | SPACER, SPRING |
| 30157318-2 | SPACER, SPRING |
| 30157318-3 | SPACER, SPRING |
| 118844-16-8 | BEARING, SELF LUB, 1.00 ID X.50 LG |
| 118844-16-12 | BEARING, SELF LUB, 1.00 ID X.75 LG |
| M614004374-4-B | NAMEPLATE, PIPE HANDLER |
| 53301-4-3 | SCREW, DRIVE – TYPE U |
| 118844-22-22 | BEARING, SELF LUB, 1.375 ID X.50 |
| 30172179 | BAR, SAFETY, CLAMP CYLINDER |
| 30172825 | PIN, PIVOT |
| 30172060 | NUT, HEX, MODIFIED, PH60/85 |
| 50216-C | NUT, HEX HD, SLOTTED 1.00-8 |
| 51604-6-C | PIN, ROLL, 0.250 X.75 LG |
| 30114259 | PIN, SAFETY |
| 30157297 | HANGER, CLAMP ASSEMBLY |
| 30157426 | SCREW, DRILLED SHANK |
| 50516-S | NUT, HEX-SLOTTED |
| 51435-16-S | PIN, COTTER |
| 30184320-502 | BUSHING |
| 120557 | CYLINDER, DOUBLE ROD |
| 120557-500 | CYLINDER, DOUBLE ROD WITH LIP SEALS |
| 120557-LT | CYLINDER, DOUBLE ROD WITH LIP SEALS |
| 120557-501 | CYLINDER, DOUBLE ROD WITH LIP SEALS |
| 103141-25 | KNUCKLE, ROD MALE |
| 103141-8 | CLEVIS, ROD FEMALE |
| 124902 | GATE |
| 30157221 | BODY, CLAMP CYLINDER |
| 11085 | RING, CYLINDER HEAD |
| 30178847 | PIN, HINGE |
| 30124898 | STABILIZER, FRONT |
| 30158690 | LINER, STABILIZER |
| 30125052 | JAW ASSY, NC50 – 5 1/2 FH (06.25-7.50) |
| M614004317-500 | PLATE, RETAINER, PIN, HINGE |
| M614004316 | BOLT, STAND-OFF |
| 30178859 | RETAINER, HINGE PIN |
| 50005-20-C5D | SCREW, HEX HD |
| 50816-N-C | WASHER |
| 51403-14-S | PIN, COTTER |
| 51402-8-S | PIN, COTTER |
| 30177109-04 | MODIFIED, SHOULDER BOLT |
| 50108-14-C | SCREW, CAP, SOC HEAD |
| 56405-20-C | PIN, CLEVIS |
| 30178854-05 | SPLIT RING, SS |
| 50508-C | NUT, HEX-SLOTTED |
| 125059 | GUIDE, STABBING, GATE |
| 125057 | GUIDE, STABBING, CLAMP CYL. |
| 76443 | SPRING |
| 76442 | GUIDE, ARM |
| 76445 | RETAINER |
| 50008-13-C5D | CAP SCREW, HEX DRILLED HEAD |
| 50810-N-S | WASHER, FLAT, NARROW |
| 51402-8-S | PIN, COTTER |
| 30172178 | PIN, GUIDE ARM |
| 124925 | JAW |
| 16401-2 | DIE, TONG |
| 124935 | RETAINER, DIE |
| 122112 | BOLT, RETAINER |
| 112489-2 | MANIFOLD, CLAMP CYLINDER |
| 94537-130N | CARTRIDGE, CHECK (PILOT TO CLOSE) (CODA-XCN) |
| 56557-8-8-S | ELBOW, 45* O-RING BOSS/37' |
| 51300-210-B | O – RING, SIZE -210 |
| 80098 | SPACER SUB |
| 77408 | WRENCH,.875 HEX |
| 125051 | JAW ASSEMBLY, 04.75-06.00 O.D. TOOL JOINT |
| 125052 | JAW ASSEMBLY, 06.25-07.50 O.D. TOOL JOINT |
| 125053 | JAW ASSEMBLY, 0.70-08.62 O.D. TOOL JOINT |
| 30173233 | JAW ASSEMBLY, 03.50-04.31 O.D. TOOL JOINT |
| 125157 | STABBING GUIDE ASSEMBLY, 04.75-06.00 O.D. TOOL JOINT |
| 125158 | STABBING GUIDE ASSEMBLY, 06.25-07.50 O.D. TOOL JOINT |
| 125159 | STABBING GUIDE ASSEMBLY, 07.50-08.63 O.D. TOOL JOINT |
| 30173442 | STABBING GUIDE ASSEMBLY, 03.50-04.31 O.D. TOOL JOINT |
| 30157433 | SAVER SUB, 6 5/8 F.H (PH75) |
| 123221-1 | SAVER SUB, 6 5/8 REG X 5 1/2 F.H. |
| 76666-2 | SAVER SUB, 6 5/8 REG X NC50 |
| 78656-1 | SAVER SUB, 6 5/8 REG/SHORT X NC46 |
| 118952-1 | SAVER SUB, 6 5/8 REG/SHORT X NC40 |
| 30157411 | SAVER SUB, 6 5/8 REG X XT39 |
| 30172182 | SAVER SUB, 6 5/8 REG X XT57 |
| 30173142 | SAVER SUB, 6 5/8 REG X PH-6, 3 1/2 OD |
| 30179163 | SAVER SUB, 6 5/8 REG X VT40(TAURUS), 4 7/8 OD |
| 117185-500 | SAVER SUB, 6 5/8 REG X HT38 |
| M614004201 | SAVER SUB, API 6-5/8 REG RH X 3-1/2 XT31 |
| M614004240 | SAVER SUB, API 6-5/8 REG RH X 2-7/8 HT-PAC |
| 30125012 | LINER, STABILIZER |
| 85705 | CROSSOVER SUB, 6 5/8 REG X 6 5/8 F.H |
| 79410-4 | CROSSOVER SUB, 6 5/8 REG X 5 1/2 F.H. |
| 79410-3 | CROSSOVER SUB, 6 5/8 REG X NC50 |
| 115595 | CROSSOVER SUB, 6 5/8 REG X NC46 |
| 120822 | CROSSOVER SUB, 6 5/8 REG X NC40 |
| 114542-600 | CROSSOVER SUB, 6 5/8 REG X HT40 |
| 110852 | CROSSOVER SUB, 6 5/8 REG X NC38 |
| 129090-375 | CROSSOVER SUB, 6 5/8 REG X HT55 |
| 30157412 | CROSSOVER SUB, 6-5/8 REG X XT39 |
| 30172183 | CROSSOVER SUB, 6-5/8 REG X XT57 |
| 30173144 | CROSSOVER SUB, 6-5/8 REG X PH-6, 3 1/2 OD |
| 30179164 | CROSSOVER SUB, 6-5/8 REG X VT40(TAURUS), 4 7/8 OD |
| M614001949 | CROSSOVER SUB, 6-5/8 REG X HT38 |
| M614004258 | CROSSOVER SUB, API 6-5/8 REG RH X 3-1/2 XT31 |
| M614004259 | CROSSOVER SUB, API 6-5/8 REG RH X 2-7/8 HT-Pac |
| M614004365 | STABBING GUIDE ASSEMBLY, 03.12-04.12 O.D. TOOL JOINT |
| M614004362 | JAW ASSEMBLY, 03.12-04.12 O.D. TOOL JOINT |
| 50108-20-C | SCREW, SOCKET HEAD CAP-.500-13 UNC X 2.50 LG |
| 50108-16-C | SCREW, SOCKET HEAD CAP-.500-13 UNC X 2.00 LG |
| 50108-12-C | SCREW, SOCKET HEAD CAP-.500-13 UNC X 1.50 LG |
| 50108-24-C | SCREW, SOCKET HEAD CAP-.500-13 UNC X 3.00 LG |
| 50108-28-C | SCREW, SOCKET HEAD CAP-.500-13 UNC X 3.50 LG |
| 51108-C | WASHER, LOCK-HIGH COLLAR 0.500 NOM |
| 16532 | KEY |
| 121732 | WELDMENT, ENCLOSURE |
| 116551 | RHEOSTAT ASSY, THROTTLE |
| 121012-1 | GASKET, ENCLOSURE |
| 122627-46 | REMOTE 24 DI/800, 24VDC |
| 122627-45 | REMOTE 4 ANALOG INPUT |
| 122627-47 | REMOTE 4 ANALOG OUTPUT |
| 81736-2 | POTENTIOMETER, 10 K |
| 30087708-46 | POTENTIOMETER OPERATOR |
| 122627-58 | REMOTE I/O BASE, DIGITAL |
| 122627-57 | REMOTE I/O BASE, ANALOG |
| 122627-34 | BUS CONNECTOR (PROFIBUS) |
| 96290 | REG. MODULE, +24VDC/+5VDC |
| 96218-3 | METER, RPM, 0-10VDC (0-250 RPM) |
| 30087708-17 | PUSHBUTTON, ILLUMINATED, AMBER, W/GUARD |
| 30087708-67 | PUSHBUTTON, E-STOP. MUSHROOM |
| 30087708-33 | SWITCH, SEL-3 POS, SPRING RTN FROM RIGHT |
| 30087708-30 | SWITCH, SEL-3 POS, SPRING RTN TO CENTER |
| 30087708-02 | SWITCH, PUSHBUTTON |
| 30087708-40 | INDICATING LIGHT, AMBER |
| 30087708-38 | INDICATING LIGHT, RED |
| 30087708-44 | INDICATING LIGHT, 2 WATT |
| 56621-18-8 | WIRE, STRANDED, HOOK-UP |
| 87975 | CABLE, 2 TWISTED PAIR |
| 56610-01 | TERMINAL, WIRE-SPADE |
| 78725-02 | FERRULE, 20 AWG |
| 78725-03 | FERRULE, 18 AWG |
| 78725-05 | FERRULE, 12 AWG |
| 122443-9-H | CABLE, PIGTAIL, 5 TSP, CONNECTORIZED |
| 125041 | H-RAIL, 33 INCH |
| 85038-UL-2.5 | TERMINAL BLOCK |
| 85039 | ENDPLATE, TERMINAL |
| 90153 | END CLAMP |
| 85145-6-001 | MARKERS, HORIZONTAL (#1-10) |
| 85145-6-011 | MARKERS, HORIZONTAL (#11-20) |
| 85145-6-021 | MARKERS, HORIZONTAL (#21-30) |
| 50649-68 | SCREW, MACHINE, PAN HD. 10-32 |
| 50649-61 | SCREW, MACHINE, PAN HD. 10-32 |
| 50803-R-S | WASHER, FLAT NO. 10 |
| 50903-S | WASHER, LOCK, NO. 10 |
| 50202-S | NUT, HEX, 8-32 |
| 50802-R-S | WASHER, FLAT, NO. 8 |
| 50902-S | WASHER, LOCK, NO. 8 |
| 50604-6-S | SCREW, MACHINE, FLAT HD, 1/4-20 |
| 50204B | NUT, HEX, 1/4-20 |
| 50202-B | NUT, HEX, 8-32 |
| 96206-3 | LABEL, NFPA 496 Z PURGE |
| 110869 | RIVET, SEALING, CLOSED END |
| 81778 | SWITCH, DIFFERENTIAL PRESSURE |
| 88493 | ELBOW, FEMALE, 1/4 X 1/8 |
| 88491 | ELBOW, MALE, 1/4 X 1/8 |
| 52002-12-B | NIPPLE, PIPE, 1/8 NPT X 1.5 LNG |
| 80430 | TUBING, 1/4 |
| 53227 | TEFLON TAPE |
| 78910-BSC | RTV, 108, CLEAR |
| 53200-454 | COMPOUND, LOCKING, CLEAR |
| 88650 | GREASE, LITHIUM BASED |
| 96219-10 | METER, TORQUE, TDS-10 (0-40K FT LB) |
| 96219-11 | METER, TORQUE, TDS-9S/11S (0-60K FT LB) |
| 30121239-BSC | NAMEPLATE, VDC, STANDARD |
| 30121239-2 | NAMEPLATE, VDC, VERTICALLY MOUNTED |
| 30121239-3 | NAMEPLATE, VDC, WITH STANDJUMP |
| 30121239-4 | NAMEPLATE, VDC, WITH ELEVATOR AND STANDJUMP |
| 30087708-36 | SWITCH, SEL-3 POS, MAINTAINED |
| 30087708-26 | SWITCH, SEL-2 POS, MAINTAINED |
| 87124 | HORN, 24 VOLT |
| 88663 | J-BOX HORN |
| 88050-200228 | GROMMET, 5/8 I.D. |
| 55203-S | NUT, HEX, 10-32 |
| 53001-02-S | PLUG, PIPE, 1/8 -27 NPT |
| 30121239-7 | NAMEPLATE, VDC, VERTICAL, ELEVATOR AND STANDJUMP |
| 30121239-6 | NAMEPLATE, VDC, STANDJUMP AND BX ELEVATOR |
| 124517-501 | GUIDE BEAM, INTERMEDIATE SECTION (12 FT) |
| 124517-503 | GUIDE BEAM, INTERMEDIATE SECTION (6 FT) |
| 124517-502 | GUIDE BEAM, INTERMEDIATE SECTION (24 FT) |
| 30154381 | GUIDE BEAM, BOTTOM, INTERMEDIATESECTION (24FT) |
| 117782 | PIN, JOINT |
| 117783 | PIN, RETAINER |
| 117496-1 | PIN, LYNCH |
| 30154900-BSC | LINK, HANG-OFF |
| 30154900-500 | LINK, HANG-OFF |
| 30154900-501 | LINK, HANG-OFF |
| 30154900-502 | LINK, HANG-OFF |
| 30154900-503 | LINK, HANG-OFF |
| 70851 | SLING, ROPE, WIRE, 25 TON |
| 30179942 | ASSY, BEAM HOIST |
| 124517-BSC | GUIDE BEAM, INTERMEDIATE SECTION (18 FT) |
| 3154688-103 | CROWN HEIGHT = 103 FT (USED CC M614003251) |
| 3154688-108 | CROWN HEIGHT = 108 FT (USED CC 30181405) |
| 3154688-136 | CROWN HEIGHT = 136 FT (H&P SPECIAL WITH SHORT HOOK/BLOCK) |
| 3154688-142 | CROWN HEIGHT = 142 FT (OBSOLETED, USE 142A) |
| 3154688-142A | CROWN HEIGHT = 142 FT (120" BAIL TO BLOCK, OR 144" HOOK/BLOCK COMBO TO 88" BAIL)) |
| 3154688-147A | CROWN HEIGHT = 147 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-150A | CROWN HEIGHT = 150 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-152A | CROWN HEIGHT = 152 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-156A | CROWN HEIGHT = 156 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-157A | CROWN HEIGHT = 157 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-160A | CROWN HEIGHT = 160 FT (WITH 120 IN. BAIL TO CLOCK) |
| 3154688-164 | CROWN HEIGHT = 164 FT (OBSOLETED, USE 164A) |
| 3154688-164A | CROWN HEIGHT = 164 FT (WITH 120 IN. BAIL TO CLOCK) |
| 30154905 | HANG-OFF TIEBACK |
| 30154700 | INT. TIEBACK |
| 50016-61-C5D | SCREW, CAP-HEX HEAD |
| 119973 | STRAP |
| 112893-1 | ROD, THREADED |
| 50416-C | NUT, HEX |
| 30117731 | FLANGE CLAMP |
| 117982 | PLATE, TIEBACK |
| 30154683 | TIEBACK LINK |
| 30154865-DWG | DRAWING, KIT, TIEBACKS |
| 30154700-DWG | DRAWING, INSTALL RESTRAINT |
| 117977-DWG | DRAWING, KIT, TIEBACK KIT |
| 124345-501 | BRACKET ASSY, SKID, 39.5 SET BACK |
| 124345 | BRACKET ASSY, SKID, 30.0" SET BACK |
| 30170891-501 | BRACKET ASSY, SHIPPING 39.5" |
| 30170891 | BRACKET ASSY, SHIPPING 30.0" |
| 30154382-500 | GUIDE BEAM, BOTTOM SECTION |
| 30113497 | U-BOLT, 1.00-8 |
| 30113498 | TUBE, 3" X 5" X 32" |
| 30154382 | GUIDE BEAM, BOTTOM SECTION |
| 116867 | PLATE, CABLE MOUNTING |
| 30170059 | ASSY, DERRICK SADDLE |
| 116869 | J-BOLT CLAMP |
| 51812-C | NUT, SELF-LOCKING HEX HEAD, 3/4-10 |
| 50012-14-C5D | SCREW, CAP HEX HEAD 3/4-10 X 1.75 |
| 50812-W-C | WASHER, FLAT, WIDE 3/4 |
| 7887 | PIN, HITCH |
| 50008-14-C5D | SCREW, CAP HEX HEAD 1/2-13 X 1.75 |
| 30170057 | ASSY, DERRICK TERMINATION |
| 30170057-500 | ASSY, DERRICK TERMINATION |
| 126815-DWG | TERMINATION KIT, MID DERRICK |
| 56004 | OIL, GEAR, STD TEMP (-20 C (-4 F) TO 38 C / 100 F) EP4 |
| 56001 | OIL, HYDRAULIC, 55 GAL DRUM |
| 56004-2 | OIL, GEAR, HIGH TEMP (ABOVE 38 C / 100 F) EP6, 55 GAL DRUM |
| 56004-1 | OIL, GEAR, LOW TEMP (BELOW -20 C / 14 F) EP2, 55 GAL DRUM |
| 122198 | OIL, SYN, GEAR, LOW TEMP EP4, 55 GAL DRUM |
| P614000064 | OIL, HYDRAULIC, LOW TEMP (-40C), 55 GAL DRUM |
| 30176013 | PUMP, LUBE OIL, 11 OZ/REV, 3/4 NPT |
| 55914-12 | DUST PLUG, 3/4 |
| 55908-12-12S | VALVE COUPLER, QD, 3/4" FEMALE NPT |
| 59124P290180 | HOSE ASSEMBLY 180 |
| 56506-12-12S | ELBOW, 90 EXT PIPE/ EXT 37 JIC |
| 56501-12-12S | ADAPTER, EXT PIPE/ EXT 37 JIC |
| 30175019 | SERVICE LOOP KIT |
| 30175017-86-4-3-B | 30175019-86-200 |
| 86 FT TDS-11S SERVICE LOOPS WITH 4 FT | |
| 122517-200-25-3-B | DERRICK PIGTAILS AND 3 FT MOTOR PIGTAILS |
| 30183959-200-25-4-B | TO FIT TDS-11S |
| 30175017-75-4-3-B | 30175019-75-200 |
| 122517-200-25-3-B | 75 FT TDS-11S SERVICE LOOPS WITH 4 FT |
| 30183959-200-25-4-B | DERRICK PIGTAILS AND 3 FT MOTOR PIGTAILS |
| 30175017-65-4-3-B | 30175019-65-200 |
| 65 FT TDS-11S SERVICE LOOPS WITH 4 FT | |
| DERRICK PIGTAILS AND 3 FT MOTOR | |
| 122517-200-25-3-B | PIGTAILS. ALL LOOPS HAVE CONNECTORS AT |
| 30183959-200-25-4-B | DERRICK PLATE |
| 30175017-86-4-3-B | 30175019-86-86 |
| 86 FT TDS-11S SERVICE LOOPS WITH 4 FT | |
| DERRICK PIGTAILS AND 3 FT MOTOR | |
| 122517-86-4-3-B | PIGTAILS. ALL LOOPS HAVE CONNECTORS AT |
| 30183959-86-4-4-B | DERRICK PLATE |
| 30175017-86-4-3-B | 30175019-86-220 |
| 86 FT TDS-11S SERVICE LOOPS W/4 FT | |
| DERRICK PIGTAILS AND 3 FT MOTOR | |
| 122517-200-45-3-B | PIGTAILS. AUX POWER AND CONTROL LOOP |
| 30183959-200-45-4-B | PIG TAILS AT DERRICK FLOOR ARE 45 FT. LONG. |
| 30175017-75-4-3-B | 30175019-75-75 |
| 75 FT TDS-11S SERVICE LOOPS WITH 4 FT | |
| DERRICK PIGTAILS AND 3 FT MOTOR PIGTAILS | |
| 122517-75-4-4-B | TO FIT TDS-11S. ALL LOOPS HAVE |
| 30183959-75-4-4-B | CONNECTORS AT DERRICK PLATE |
| 124977 | HOUSE TO DERRICK LOOP JUMPER KIT |
| 78310-1 | WASHER, BELLEVILLE, 1/2" |
| 50808-R-S | WASHER, FLAT, 1/2" |
| 50208-S | NUT, SELF-LOCKING, 1/2" |
| 50008-12-S | SCREW, HEX, 1/2" X 1 1/2 |
